Carverall Laser Engraver | Z3 Galvo
Portable and Handheld Laser Engraver for Beginners
Create anywhere your inspiration leads
With its compact and portable design, the Z3 goes wherever your creativity demands. Whether you're customizing products on-site or laser marking in tight or remote spaces, the Z3 delivers precision and convenience in one powerful tool.
Dual Optical FocusFor Sharper, More Accurate Engraving
Up to 2K High Resolutions
2K Realistic Details
Realistic engraving quality up to 2K high resolution, clearly restoring all tiny details of photos.
0.05mm Engraving Accuracy
Precise down to 0.05mm, delivering accuracy for intricate engraved details.
Engraving Speed 800mm/s
Complete engraving tasks fast, every time.
Bevel Engraving
The laser head of the Z3 can be tilted to the desired angle, allowing precise engraving on beveled or angled surfaces.
Workable on more than 120+ materials
Wood
Bamboo
Paper
Cork
Stone
Leather
Glass
Fabric
Carverall Design Studio
Customize, design and craft at fingertips.
After-sales Support
Accessories Come with Z3
Specifications
| Parameter | Details |
|---|---|
| Laser Type | 455nm Blue Diode Laser |
| Laser Power | 5W Light Compression Technology |
| Engraving Area | 80x80mm |
| Engraving Speed | 800mm/s |
| Laser Spot Size | 0.05mm |
| Focus Mode | Auto Focus |
| Resolution | 1K/2K/4K |
| Applicable Materials | [Engrave] Wooden materials, bamboo materials, acrylic, leather, paper, cloth, wool, corrugated paper, food, fruits, plastic, bone, alumina alloy, glass, shale/brick block/cement, stainless steel, paint surface Metal, ceramic, etc. [Cutting】 Wooden board, paper, cloth, leather, acrylic, corrugated paper, etc. |
| Preview Mode | Square Preview + Graphical Preview |
| Software | "BSLAPP"/Carverall-"Engraver" |
| File Format | PC: G-Code/JPG/PNG/BMP/SVG/DWG/DXF etc. Vector Format APP: JPG/PNG/G-Code/SVG |
| Connection | Mobile - Wireless Bluetooth 5.0+ PC - USB Connection / Wireless Bluetooth 5.0+ (Dongle Required) |
| Operating System | Windows, MAC, Android |
| System Languages | German/Spanish/French/English/Japanese/Korean Simplified Chinese/Traditional Chinese |
| Safety Certificate | CE, ROHS, FCC, FDA, CDRH, NCC, KC, UKCA, TELEC |
| Input Power | <60W |
| Dimensions | 220x130x220mm |
FAQ-CarverAll Z3 Laser Engraver
1. What materials can the Z3 engrave and cut?
The Z3 is compatible with a wide range of materials:
- Engraving: wood, bamboo, acrylic, leather, paper, fabric, felt, corrugated cardboard, food, fruits, plastic, bone, anodized aluminum, glass, shale/brick/concrete, stainless steel, painted metal, ceramics, and more.
- Cutting: wood boards, paper, cloth, leather, acrylic, and corrugated cardboard.
2. Is the Z3 suitable for beginners?
Absolutely. The Z3 features auto-focus, a foldable structure, and intuitive software, making it easy to operate even for first-time users.
3. What is the engraving area and speed?
The Z3 supports an engraving area of 80×80mm and offers speeds up to 800mm/s, ideal for efficient, high-speed production.
4. Is it compatible with both computers and mobile devices?
Yes. The Z3 is powered by our proprietary Engraver App, which supports both PC and smartphone control for maximum convenience.
5. Can I use the Z3 for professional applications?
Yes. Thanks to its high precision, speed, and compatibility with various materials, the Z3 is widely used in small business production, DIY customization, craft workshops, and more.
6. Does the Z3 come with customer support and warranty?
All CarverAll machines include 1-year warranty and lifetime technical support. Our responsive support team is ready to help anytime you need assistance.
